Car Rear View Mirror Camera Front And Rearview Camera HD Dual View

Brand Name:	Customized
MOQ:	300
Price:	Negotiatable
Payment Terms:	T/T,L/C
Supply Ability:	100000/Month

Detail Information

Product Description

Detail Information

Certification:

E-Mark, CE, FCC, RoHS

Feature 1:

Rearview 120dB HDR

Feature 2:

60 Fps

Feature 3:

Anti-glare Functionality

Feature 4:

Enhanced Visibility

Feature 5:

Video Streaming

Feature 6:

Recording Capabilitie

Feature 7:

Night Vision

Feature 8:

Reverse Parking Assistance

Application:

Automotive

Packaging Details:

Regular Export Packaging, Customized

Supply Ability:

100000/Month

Highlight:

Car Rear View Mirror Camera

Dual View Rear View Mirror Camera

Night vision rearview camera

Product Description

SYSTEM INTRODUCTION

The high-definition streaming rearview mirror utilizes advanced real-time display technology. Through a fully high-definition, distortion free, night vision wide-angle camera installed at the rear of the vehicle, the rear image of the vehicle is displayed on the display screen. The wide-angle camera has a viewing angle of more than three times that of traditional rearview mirrors, and a longer viewing range. Additional HD driving record function, keep away from collisions, and clearly record every moment of driving. Not only can it curb traffic violations and constrain drivers' bad driving habits, but it can also effectively prevent road traffic accidents and provide scientific and faithful original data for law enforcement personnel to analyze and handle accidents, playing a very important role in transportation management.

SYSTEM FUNCTIONS

No	Item	Descricption
1	System on/off	When ACC ON,Default system startup, startup time ≤ 5S The recording function of the recorder can be turned off or on by pressing the button
2	Image display	When the display screen is turned on, real-time display of the rear recorded camera image with a delay of<100 milliseconds
3	Brightness adjustment	The brightness of the display screen can be automatically adjusted with ambient light, and users can manually adjust it
4	HDR	Supports HDR function, with a dynamic range of ≥ 120dB (rear view)
5	Touch screen	Adopts touch screen control to achieve angle adjustment, front and back switching, DVR setting, and on/off operation

SYSTEM COMBINATION

NO.	Component	QTY	Remarks
1	HD display screen	1	with mounting bracket
2	HD front view camera	1	with mounting bracket
3	HD rear view camera	1	with mounting bracket
4	Wiring Harness	1

TFT Screen Specification

NO	ITEM	CANDIDTECH
1	Resolution	1920*480
2	Size	9.66″
3	Video Interface	MIPI
4	Brightness	800cd/m2
5	Brightness Adjustment	Automatically adjusts brightness while supporting manual adjustment
6	Display Area	222.32mm(H)x 58.08mm(V)
7	Frame Size	236.15(H) x 64.48(V)

Specification of Front view camera

NO	ITEM	CANDIDTECH
1	Resolution	1920*1080 (2M pixels)
2	Lens Viewing Angle	H:120° ,V:60°
3	Dynamic Range	80dB
4	Aperture	F/NO:1.8
5	Frame Rate	30fps
6	Interface	MIPI CSI

Specification of rear view camera

The rear recording camera adopts OV image sensor, outputs 1080P/60fps, supports starlight night vision with HDR and 120dB dynamic range.

NO	ITEM	CANDIDTECH
1	Resolution	1920*1080(2M pixels)
2	FOV	H:80°,V:43°
3	Dynamic Range	120dB
4	Aperture	F1.8
5	Frame Rate	60 fps
6	Transmission signal	AHD
7	Waterproof class	IP67/IP69

INSTALLATION
