64G TF Card Universal Dash Cam with Front and Rear Dual Recording and Real-time Video Checking

Brand Name:	Customized
MOQ:	300
Price:	Negotiatable
Payment Terms:	T/T,L/C
Supply Ability:	100000PCS/Month

Detail Information

Product Description

Detail Information

Certification:

E-Mark, CE, FCC, RoHS

Customization:

OEM/ODM

Monitoring:

Real-time Video Checking

Output:

High Definition

Calibration:

Ultra Wide Angle

Recording:

Front View Recording Or Front And Rear View Dual Recording Optional

Storage:

64G TF Card

Application:

Automotive

Packaging Details:

Regular Export Packaging, Customized

Supply Ability:

100000PCS/Month

Highlight:

64G TF Universal Dash Cam

ODM Universal Dash Cam

OEM dashcams

Product Description

Important Notice: Installation and usage of car cameras and dash cameras must comply with local laws and regulations.

Product Specifications

Front Camera

Horizontal FOV	120±3°
Vertical FOV	62±3°
Horizontal Resolutions	≥ 630 TV Line
Vertical Resolutions	≥ 600 TV Line
F/No	1.8
Waterproof Level	IP5K5K
Structure	6G+IR Filter

Image Sensor

Resolutions	1928(H) x 1088(V) (16:9 mode)
Sensitivity	4.0 V/lux-sec
Night Vision	Low light level night vision
Frame Rate	30 fps (1080P)
SNR	48dB min
Dynamic Range	120dB min
Minimum Illumination	50IRE@0.1 Lux
Maximum Illumination	100,000 Lux

Memory

Capacity	8~32GB (can be recorded for 6h)
Video Files	MP4
Data Protection	File encryption function
Data Processing	When memory card is full, new videos overwrite old ones
Image Compressed Format	H.264
Compression Ratio	200:1

Operation Mode

Collision Lock Recording	Automatic lock protection when collision detected
Privacy Protection	Sound turn-off optional
Circular Recording Mode	Recording time 1/3/5 minutes setting optional
Auto Power On	Yes

Video Output

Video Format	NTSC
Output Interface	CVBS signal connect with Wi-Fi then output to mobile phone APP
Frame Correction	Build-in

Power

Power Supply	Battery + ACC
Operation Voltage	9~16VDC
Operation Current	270mA
Quiescent Current	< 1mA
Power Consumption	3W

General

Operation Temperature	-20℃～70℃
Storage Temperature	-40℃～95℃
DVR Weight	450g (for reference only)

Rear-view Recording Kit (Optional)

Horizontal FOV	120°±3°
Vertical FOV	62°±3°
Image Compressed Format	H.264 (MP4)
Photo Format	JPG
Video Pixel	2 million pixels
Video Output Signal	LVDS
Operation Voltage	5VDC
Minimum Illumination	0.1 lux
Frame Rate	30 fps
Waterproof Level	IP6K9K
Resolutions	1920(H) x 1080(V)

Special Functions

Ultra Wide Angle Image Calibration

Wi-Fi Connect: Real-time Video Display

Watch real-time video on your smartphone, with adjustable camera and viewing angle during installation.

Real-time video output to smartphone
Smartphone functions as a monitor
Adjust camera viewing angle through smartphone APP

Wi-Fi Connect: Video Playback

Access video playback directly on your smartphone.

Continuous 1080P video recording
Connect with smartphone APP through Wi-Fi
Previous video playback capability
Copy videos to smartphone
Upload videos to internet via smartphone

Installation Guide

For left-hand drive vehicles, the recommended installation position is to the right of the rear view mirror. Actual installation position may vary depending on vehicle type.

Rear view camera is optional. The dash camera can work with rear view camera to record surroundings from both front and rear.

Our product lines cover various vehicle camera applications including rear view, front view, side view, around view, Dash Cameras, Around View Monitoring Systems, ADAS products, CMS, OMS, DMS, and more.
